DG400-2 (Single-phase)
US
Metric
Overview
Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.
Generator Set Specifications
Speed
1800 RPM
Speed
1800 RPM
Speed
1800 RPM
Speed
1800 RPM
Speed
1800 RPM
Speed
1800 RPM
Speed
1800 RPM
Engine Specifications
Engine Model
G21.9L spark-ignited
Gas Generator Sets Specification
Compression Ratio
0.00
0.00
Displacement
1336.42
14.17 l
Fuel Type
Natural Gas
RPM
1800
Generator Set Specifications
Voltage
120/240VAC
Generator Set Configurations
Emissions/Fuel Strategy
U.S. EPA Certified for Stationary Emergency Application
Engine Specifications
Bore
5.03 in
21.90 mm
Fuel System
Natural Gas
Stroke
5.60 in
152.40 mm
Generator Set Specifications
Frequency
60 Hz
Speed
1800 RPM
Speed
1800 RPM
Standard Equipment
- Cooling
- Closed coolant recovery system
- Factory-installed radiator
- 50/50 Ethylene glycol antifreeze
- Fuel
- Primary and secondary fuel shut-off
- Fuel pressure test po
- Low fuel pressure switch
- Generator
- Class H insulation material
- Permanent magnet excitation
- Full load capacity alternator
- Controls
- EMCP 4.2 Series generator set controller
- Mounting
- Vibration isolaton (puck type)
- Electric Starting and/or Prelube
- Engine electrical system
- Solenoid activated starter motor
- Battery cables
- Electric Power - Package Serial Number Prefix
- Battery charging alternator
Optional Equipment
- Generator
- Shunt trip and auxiliary contact breaker
- Thermal magnetic or electronic trip MCCBs
- Anti-condensation heater
